Dometic RUA 8508X 3 Way 216 Litre Dual Hinge Fridge & Freezer
SKU: 9620017227 Learn More»
Absorption Refrigerator
FREE SHIPPING
This item is sent via Express Courier. All freight is fully insured.
Recommended Accessories
Dometic RUA 8508X 3 Way 216 Litre Dual Hinge Fridge & Freezer
The Dometic RUA 8508X is a large capacity 3 way absorption fridge with a narrow cabinet design. The benefits to the narrow cabinet design firstly are easy installation as you can simply fit the fridge through your RV door, as well as maximising flexibility of your kitchen space without compromising on storage volume.
The Dometic RUC8508X refrigerator has undergone extensive research and development with the result being the most refined RV refrigerator on the market. At the centre of the Dometic RUC8508X’s design is its tall and narrow cabinet, which allows for greater flexibility in the kitchen area without compromising on storage volume.
Due to the smaller footprint, the installation of the refrigerator is hassle-free, the service process for the Dometic RUC8508X refrigerator has also been streamlined, the result being that rather than removing windows to access the refrigerator, the RUC8508X refrigerator can be easily fit through the entrance door of your RV if required.
The stylish control panel is intuitive and easy to use. The control panel allows users to select the interior compartment temperature, power source, and a variety of pre-set modes; including performance, silent and power-save. Users can simply click and turn the selection wheel to navigate through the settings on the TFT colour display. The control panel also features a built-in service mode that creates simple diagnostics if required.
- Reliable refrigeration performance
- Built-in circulation fans ensure that food and beverages are cooled quickly
- Full-width crisper with humidity control for fruit and vegetables
- Freezer and refrigerator doors include shelving
The T-rated cooling systems ensure excellent performance in both high and low ambient temperatures, making the RUA & RUC refrigerators an excellent choice for all conditions. The built-in control panel is intuitive and easy to use, allowing users to select a temperature range and a variety of preset modes. The control panel also features a built-in service mode that creates simple diagnostics if required. Coloured error messages are displayed alongside an audible alarm if errors occur.
Features:
- Narrow design with slim footprint - easy to install
- T-rated cooling system
- Control panel with intuitive colour TFT display
- Interior LED lighting and audible alarm
- Reversible door hinges
- Fully adjustable wire shelves with included shelf guards
- Full-width crisper with humidity control
- Generous storage capacity of 216 l
- Narrow cabinet design with slim footprint
- T-rated cooling system ensures excellent cooling performance in all conditions
- Automatic switching from DC to AC power when AC mains is available
- Easy-to-use control panel with colour TFT display
- Adjustable shelves and door bins
Specifications:
- Dimensions: 667mm (d) x 1661 mm (h) x 550mm (w)
- Recess Dimension: (d) min. 621mm x (h) 1652-1657mm x (w) 530-535mm
- Operation: 12V (required), 240V
- Gross Volume: 216L
- Fridge Storage Volume: 170L
- Freezer Storage Volume: 46L
- Weight: 73kg
- Warranty: 3 years
- Climate Class: T
Note: This is a replacement model for Dometic RUA 8408X, this is now called RUA 8508X and is a Dual Hinge fridge
-
For recommendations on appropriate accessories to go with the refrigerator (and advice on optimal ventilation set-up), please click on the below INSTALLATION GUIDE.
-
Absorption 3 way refrigerators need to be installed and certified by a qualified and licensed gas-fitter, as improperly or illegally installed products will void the manufacturer’s warranty, and could pose a safety risk.
-
While 3 way absorption fridges have the ability to run off 3 different power sources (12V / 240V / Gas), they are primarily designed with gas operation in mind; they provide exceptional efficiency when running on gas. However for 12 Volt operation, this is only recommended with absorption fridges when the vehicle is running, otherwise it can exhaust your 12 volt power source (battery) very quickly.
Specifications
SKU 9620017227
Brand Dometic
Product Category Upright RV Absorption Fridges
Total Capacity (L) 216
Gas Certification Number GMK10711
Certified By IAPMO
Fridge Width (mm) 550
Fridge Height (mm) 1661
Fridge Depth (mm) 667
Model RUA8508X
Weight (kg) 73
Cut Out Required 530 – 535(w) x 1652 – 1657(h) x min. 621(d) mm (the fridge must be installed in a recess so that it stands secure when the vehicle is in motion).
Freezer Compartment 46 Litres
Voltage (V) 12 Volts DC and 230 to 240 Volts AC
Q & A
-
How do I deactivate the child-lock in my RUA/RUC model refrigerator?
These models have a great lock for children to prevent any accidental adjustments. If you are unable to change the temperature or the power source, you have most likely activated the child-lock. You can either permanently deactivate or temporarily override the lock - please see below:
Temporarily Override the Child-lock:
- First push the control knob 3 times within 1.5 seconds
- The lock will be reactive again after 10 seconds without touching the control knob
Permanently Deactivate the Child-lock:
- Start with doing a temporarily override, after that simply turn off the child lock in the settings menu
-
Does the RUA model only work on gas mode?
The battery save mode available on the RUA models will allow the refrigerator to operate in gas mode only if activated. The exterior fan and frame heater will also be deactivated in this mode. Consideration of the ambient temperature needs to be made if this setting is to be selected.
-
How often do I need to service my Dometic RV/Caravan appliances?
Dometic recommend servicing their gas appliances on a yearly basis, even if the vehicle has not been used. Additionally, bear in mind that insects can built nests in the gas appliances which will cause the appliances to stop working. It can also cause potentially dangerous scenarios.
For other appliances, such as refrigerators and air conditioners, to ensure the appliances to work efficiently and last longer it is recommended to clean the condenser.
-
What do I need to know about installing an absorption gas fridge in my Caravan?
To ensure the correct fittings and ventilation set-up for the specific absorption fridge model, please see the link to the INSTALLATION GUIDE/MANUAL in the Product Description.
A 3-Way absorption refrigerator requires to be installed and certified by a qualified and licensed gasfitter. Illegal or improperly installed absorption fridge will void the manufacturer�s warranty and could pose a safety risk.
-
I want to run my absorption on 12v power source, is this ok?
An absorption 3-way fridge is designed to be run on gas as a power source. This means that gas will be the most efficient power source.
It is only recommended to use the 12-volt setting on an absorption fridge when the vehicle is running. Otherwise, the 12-volt can exhaust the power source (the battery) very fast. It is important to remember this when you have parked and turned off your vehicle!
-
I’m looking for a Caravan Fridge: would you recommend an absorption (gas) fridge, or a compressor (12v) fridge?
This depends on what you expect of your trip and what is important for you.
Choose an absorption fridge if:
- You are free camping for extended periods.
- You want a fridge to run from your gas bottle.
Free campers often choose a 3-way model so that they do not have to worry about enough battery power during their prolonged trips away. However, remember that they are not designed to be running on 12V for an extended period, it is only for while the vehicle is running.
Choose a compressor fridge if:
- You prefer consistent cooling capacity on your fridge.
- You require a fridge with high efficiency on battery power.
- You will require an efficient cooling capacity in hot climate.
The leading brand within compressor fridges are Dometic Waeco, Bushman, Evakool and Engel. All these brands are high quality RV fridges that can provide a desired temperature quickly.
We have found that compressor fridges are becoming more trendier compare to the absorption fridge. Many of our customers choose to replace their old 3-way absorption fridge to a new 12V compressor fridge. With today�s improvements in solar and battery performance, you can run your 12V compressor fridge very efficiently and will keep your food & drinks very cool.
