TRA Manual 12V Air/Rain Roof Vent Hatch
SKU: TRA-RVM5000-AIR Learn More»
TRA Manual 12V Air/Rain Roof Vent Hatch
Looking for a powerful and reliable roof vent hatch for your RV or caravan? Look no further than the TRA Manual 12V Air/Rain Roof Vent Hatch!
With easy installation and three fan speeds, this hatch provides optimal air circulation and reversible airflow to keep you comfortable. Its motor can reach 1200 revolutions per minute at high speed, while only drawing the necessary amount of power. Plus, with its durable air/rain design, this hatch can withstand any weather conditions.
So why wait? Get your TRA Manual 12V Air/Rain Roof Vent Hatch today and start enjoying the great outdoors in comfort! It also comes with a great 1-year warranty.
Features:
- Unit operates with the lid closed and can still be used while raining
- 24/7 ventilation
- Manual lift lid with reversible airflow
- Three fan speeds
- Easy installation
Specifications:
- 12 volt/18W
- Size: 14″ (35.56 cm) x 14″ (35.56 cm)
- 1.6amps on HIGH speed
- 1200 revolutions per minute
- Unit sits 14 cm above roof line once fitted
- Internal garnish is 15cm high, this can be cut down to suit your desired roof thickness
- Suits minimum roof thickness of 40mm unless installed without internal garnish
- Airflow – HIGH：25.76m3/min – MED：18.28m3/min – LOW：13.38m3/min
Specifications
SKU TRA-RVM5000-AIR
Brand TRA
Product Category Skylights, Vents and Roof Hatches
Lid Type Manual Air/Rain lid
Insect Screen Removable for cleaning
Internal Garnish Height Approximately 150 mm – trim to suit
Low-Speed Airflow 13.38 m³/min
Medium-Speed Airflow 18.28 m³/min
High-Speed Airflow 25.76 m³/min
Intake Speeds (IN) 2 – Low and High
Extraction Speeds (OUT) 3 – Low, Medium and High
Airflow Direction Reversible – intake (IN) and extraction (OUT)
Closed-Lid Operation Yes – approximately 20% airflow with lid closed
Power 18W
Fan Speed Up to 1200 RPM
Circuit Protection Built-in overload protection fuse
Minimum Roof Thickness 40 mm when installed with internal garnish
Roof Opening 356 × 356 mm
Current draw 1.6A on high speed
Power Supply 12V
Cut out Dimensions 35.56 x 35.56 cm
Q & A
-
What thickness does this hatch suit up to?
This hatch will work on roof thicknesses from 40-150mm.
-
What is the height of the vent when closed?
It sits roughly 14cm above roof line.
-
How do I take the mesh screen off from the inside?
There will be a lip around the screen, please pull on this and slowing work your way around the diameter of the screen. Some force will be needed as its fitted snug with 6-7 lugs.
Reviews
Roof hatch fan
By: Jason on10 June 2025
Very easy to install. Works great. Will definitely get another one.
Great product
By: Nicky on6 June 2025
Excellent product, we build campervans and have used many of these. Easy to install and good value for money.
