Victron Busbar 150A/70A 2P With 10 Screws + Cover

CALCULATE SHIPPING:

Quantity

Postcode

Suburb

Learn More»

Go to: Product Details

Go to: Specifications

Description

Busbars are used for high current distribution and at the same time they provide connections for batteries and/or DC equipment.

We offer a number of busbars with different current ratings, and a different number of connection terminals. Each busbar is fitted out with a removable protection cover.

Available models:

150A / 70V - 4 high current connections
150A / 70V - 6 high current connections
150A / 70A - 2P with 10 screws +cover
150A / 70A - 2P with 20 screws +cover
250A / 70V - 4 high current connections
250A / 70V - 6 high current connections
250A / 70A - 2P with 6 screws +cover
250A / 70A - 2P with 12 screws +cover
600A / 70V - 4 high current connections and 8 low current connections
600A / 70V - 8 high current connections and 8 low current connections

Specifications:

Max. current: 150 A
Max. Voltage: 70 VDC
Terminal diameter: 6.35 mm
Terminal height: 17 mm
Terminal material: Stainless steel
Hex nut material: Tin-plated copper
Recommended torque: 7 N·m
Terminal screws: 4.2 mm
Terminal material: Stainless steel
Busbar strip material: Tin-plated copper (2.4 x 19 mm)
Base material: ABS, black, UL 94 V-0
Cover material: Clear Polycarbonate, UL 94 HB
Weight: 0.3 kg
Dimensions 10 screws (hxwxd): 45 x 152.4 x 32 mm (with cover)

Go to: Description

Go to: Warranty

Specifications

SKU VBB115021020

Brand Victron

GTIN 8719076056355

Product Category Electrical Accessories

Dimensions 10 screws (hxwxd): 45 x 152,4 x 32 mm (with cover)

Weight: 0.3 kg

NOTE: see full product specifications & further product info in the Description section on this page.
