Fiamma Security Handle 46 for RV Door, Deep Black. 03513A01H

Fiamma Security Handle 46 for RV Door, Deep Black. 03513A01H

The Fiamma Handle Security 46 (03513A01-) is a dual-purpose locking door handle that adds both security and convenience to your caravan or motorhome.
When folded across the door, it acts as a solid locking bar to help prevent forced entry. When opened out, it functions as a sturdy grab handle for safe access to your vehicle.

Designed to lock across the main door to provide extra security & also double as a grab handle to get into your caravan comfortably.

Features:

• 2-in-1 design: Works as both a grab handle and locking door security bar
• Longer 46 cm version: Ideal for taller caravan or motorhome doors
• Sturdy construction: 30 mm anodised aluminium tube for maximum strength
• Weather-resistant: Powder-coated white finish resists corrosion and UV damage
• Lockable: Integrated barrel lock with two keys for peace of mind
• Easy installation: Includes all required fixings, plates, and hardware
• Comfortable grip: Ergonomic tube diameter for secure handhold

Specifications:

• Total Height (Handle Length): 46 cm (460 mm)
• Handle Tube Diameter: 30 mm
• Overall Width (open grab-handle position): 33.5 cm (335 mm)
• Wall Projection (when folded and locked): 65 mm
• Bracket Centre-to-Centre Distance: 355 mm (vertically between brackets)
• Bracket Bolt Hole Spacing (each bracket): 50 mm
• Total Bolt-to-Bolt Distance (top bracket to bottom bracket): 415 mm
• OEM Part Number: 03513A01-
• Compatible With: Caravan and motorhome main doors
• Material: Anodised aluminium
• Colour / Finish: Blackpowder-coated aluminium

Included:

• Handle assembly
• lock barrel with keys
• mounting brackets
• backing plates
• fixing hardware
