Projecta PM300 RV Power Management System
SKU: PM300 Learn More»
FREE SHIPPING
This item is sent via Express Courier. All freight is fully insured.
Recommended Accessories
Projecta PM300 RV Power Management System
A comprehensive system building on all the functionality of PM200, but with a remote LCD display offering advanced monitoring of battery, solar, water and electrical systems, plus a full MPPT 30A solar charge controller. PM300’s remote LCD control features battery and charging information (Volts, AMPs, SOC, time remaining), up to 4 water tank level inputs with pump control, a load switch, night mode and silent mode for quiet operation. 14 channel fused output and WAGO® terminals, plus a host of protection features and sensors ensure easy, safe operation and monitoring of your electricals.
- Voltage Sensitive Relay engages & disengages with engine
- 20A Charger, 35A Power Supply
- Wago® Terminals for easy wiring
- Manual Battery Switch connection for remote & local operation
- MPPT Solar Input
- Water Level & Pump Control
Specifications:
- Power: 35A
- Charging Voltage: 12V
- Output Fuse Rating: 4 x 15A: 10 x 10A
- Dimensions (LxWxH) mm: 266 × 165 × 129
- Net Weight: 3.0 Kg
- Included: LCD Remote Control
Specifications
SKU PM300
Brand Projecta
GTIN 9315219110039
Product Category Battery Management System
Voltage 12V
Operating temperature range -40°C~+65°C (50°Cfull load; 60°C20A; 65°C shutdown the output)
Dimensions 264 x 164 x 128 mm (L x W x H)
Weight (kg) 3
Nominal Voltage 240 ± 10% VAC | 50/60Hz (Input) | 12.8 0.2 VDC (Output)
