Victron Multiplus Compact Inverter Charger 24/1600/40-16
INVERTER CHARGER
Q & A | SKU: CMP241620000 Learn More»
Description
Victron Multiplus Compact Inverter Charger 24/1600/40-16
Specifications:
Output Current Rating (Amps) | 40.0 Amps |
---|---|
Wattage | 1300W |
Peak Power | 3000W |
Output Voltage and Frequency | 230 Vac ± 2% / 50 Hz ± 0.1% |
Output Power | 1300W (continuous output power at 25°C) | 1200W (continuous output power at 40°C) | 800W (continuous output power at 65°C) |
Input Voltage | 19-33V |
Operating Temperature Range | -40 to +65°C |
AC Input | 187-265VAC | 45-65Hz | 1 |
Inverter Output Continuous Watts | 1300W (continuous output power at 25°C) |
Charge voltage 'absorption' | 28.8V |
Charge Voltage Float - Wet (25 degrees)** | 27.6 |
Charge voltage 'storage' | 26.4V |
Inverter Output Nominal Efficiency | 94% (maximum) |
No load power consumption | 10W | 3W in search mode |
Product Dimensions (mm) LxWxH | 214 x 110 x 375 |
Net Weight (kg) | 10.0 Kg |
Features:
Unique PowerAssist feature
The MultiPlus will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery.
Uninterrupted AC power (UPS function)
In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption.
Virtually unlimited power thanks to parallel operation
Up to 6 Multis can operate in parallel to achieve higher power output. Three phase or split phase operation is also possible. Please check the datasheets to see which models have paralleling, three phase and split phase capabilities.
Specifications
SKU CMP241620000
Brand Victron
GTIN 8719076022039
Product Category Power Inverter Chargers
Voltage 12V
Wattage (W) 1300
Input Voltage 19-33V
Peak Power (W) 3000
Weight (kg) 10
Dimensions 214 x 110 x 375mm
NOTE: see full product specifications & further product info in the Description section on this page.
Warranty
Warranty Period: 5 Years
Warranty Details: Please CLICK HERE for Warranty Information on this product
Delivery
- We ship Australia-wide with national road express freight companies such as Star Track, TNT and Toll.
- Small Items are sent with Australia Post via regular post.
- Delivery times are generally 3-5 days from day of dispatch for major cities (sometimes quicker). Please allow longer for regional and remote areas.
- Once your item(s) have been dispatched, we will provide you freight tracking information so you can track your delivery to your door.
- Items are fully insured during the freight process.
- Unfortunately we cannot deliver to PO Boxes.
- For further details on our Delivery Process you can visit our Delivery Page HERE.
Reviews
Be The First To Review This Product!
Help other CARAVANRVCAMPING users shop smarter by writing reviews for products you have purchased.
Q & A
-
Can these chargers take solar input?
No, the battery charging component is an AC input, meaning only AC power (mains power) can charge through this unit.
